Appendix 1. Cable and Connector Specifications
A1 - 7
(2) Servo detector cable
<CNV12/CNV13 cable connection diagram> The connection differs according to the cable length.
Servo drive unit side connecto
r
Connector: 10120-3000VE
(One-touch type lock)
Shell kit: 10320-52F0-008
(Screw-type lock)
Shell kit: 10320-52A0-008
H
J
K
L
E
S
R
N
6
16
7
17
9
19
10
20
1
11
PE
SD
SD*
RQ
RQ*
BAT
P5(+5V)
LG
FG
<For 20m or less>
Servomotor detector side/
Ball screw end detector side connector
<For general environment>
Plug: MS3106B22-14S (Straight)
MS3108B22-14S (Angle)
Clamp: MS3057-12A
<IP65 compatible>
Plug:
MS3106A22-14S(D190)
Straight back shell:
CE02-22BS-S (Straight)
CE-22BA-S (Angle)
Clamp: CE3057-12A-3
H
J
K
L
E
S
R
N
6
16
7
17
9
19
10
20
1
11
PE
SD
SD*
RQ
RQ*
BAT
P5(+5V)
LG
FG
<For 20m to 30m>
