2. Wiring and Connection
2 - 18
2-4-2 Connecting the full-closed loop system
Refer to section "2-4-1 Connecting the servomotor" for details on connecting the each motor type.
(1) Connecting the ball screw end detector
MDS-C1-V1
CN2
Servomotor
CN3
CNV13
Name
LG
SD*
RQ*
P5(+5V)
P5
(
+5V
)
Pin
11
12
13
14
15
16
17
18
19
20
Name
LG
SD
RQ
BAT
P5
(
+5V
)
Pin
1
2
3
4
5
6
7
8
9
10
CNV12
Table
U V W
Pin No.
Detector connector : CN3
No.1
No.10
No.11
No.20
Max. 30m
