5. Spindle Adjustment
5 - 42
[4] Position loop gain and deceleration rate adjustment at coil changeovers
When using a coil changeover motor, the position loop gain and deceleration rate can be set for
each coil.
• Coil-specific orientation control position loop gain
Compensation magnification values are set for each coil by the SP119, SP120 and SP126
settings, relative to each coil's SP001 or SP002 position loop gain reference value. If a "0" is set,
the SP001 (SP002) setting is adopted.
SP119
Effective position loop gain (H-coil) = SP001 (SP002) ×
256
SP120
Effective position loop gain (L-coil) = SP001 (SP002) ×
256
<<Only for MDS-C1-SPM>>
SP126
Effective position loop gain (M-coil) = SP001 (SP002) ×
256
No. Abbr. Parameter name Details
Setting
range
Standard
SP119 MPGH Orientation control
position loop gain H
coil magnification
Set the compensation magnification of the orientation position
loop gain for the H coil.
0 to 2560
(1/256-fold)
0
SP120 MPGL Orientation control
position loop gain L
coil magnification
Set the compensation magnification of the orientation position
loop gain for the L coil.
0 to 2560
(1/256-fold)
0
SP126 MPGM Orientation position
loop gain M coil
magnification
<For MDS-C1-SPM>
Set the compensation magnification of the orientation position
loop gain for the M coil.
0 to 2560
(1/256-fold)
0
• Coil-specific orientation control deceleration rate
Compensation magnification values are specified for each coil by the SP121, SP122 and
SP127 settings, relative to each coil's SP006 deceleration rate reference value. If a "0" is set,
the SP006 setting is adopted.
SP121
Effective deceleration rate (H coil) = SP006 ×
256
SP122
Effective deceleration rate (L coil) = SP006 ×
256
<<Only for MDS-C1-SPM>>
SP127
Effective deceleration rate (M coil) = SP006 ×
256
No. Abbr. Parameter name Details
Setting
range
Standard
SP121 MPCSH Orientation
deceleration rate H
coil magnification
Set the compensation magnification of the orientation
deceleration rate for the H coil.
0 to 2560
(1/256-fold)
0
SP122 MPCSL Orientation
deceleration rate L
coil magnification
Set the compensation magnification of the orientation
deceleration rate for the L coil.
0 to 2560
(1/256-fold)
0
SP127 MPCSM Orientation
deceleration rate M
coil magnification
<For MDS-C1-SPM>
Set the compensation magnification of the orientation
deceleration rate for the M coil.
0 to 2560
(1/256-fold)
0
