3. Setup
3 - 85
No. Abbr. Parameter name Details
Setting range
(Unit)
Standard
setting
FEDCBA98765 4 3 2 10
r2iro r2ini
r2am
r2lm
r2dm no51
r2ch
bit Meaning when set to 0 Meaning when set to 1 Standard
0r2ch 0
1 no51 0
2 r2dm 0
3r2lm 0
4 r2am
Set by Mitsubishi. Set "0" unless designated in particular.
0
SP075 R2KWS Fixed control constant
5 0
6 0
7 0
8 r2ini
Set by Mitsubishi. Set "0" unless designated in particular.
0
9r2iro
Set by Mitsubishi. Set "0" unless designated in particular.
0
A 0
B 0
C 0
D 0
E 0
F 0
(Note) Set 0 if there is no particular explanation for the bit.
SP076 FONS
Machine resonance
suppression filter
operation speed
When the vibration increases in motor stop (ex. in
orientation stop) when the machine vibration suppression
filter is operated by SP070, operate the machine vibration
suppression filter at a speed of this parameter or more.
When set to "0", this is validated for all speeds.
0 to 32767
(r/min)
0
SP077 TDSL* Fixed control constant
Set by Mitsubishi.
Set "14" unless designated in particular.
14 14
SP078 FPWM* Fixed control constant Set by Mitsubishi. Set "0" unless designated in particular. 0 0
SP079 ILMT* Fixed control constant Set by Mitsubishi. Set "0" unless designated in particular. 0 0
SP080 Not used. Set "0". 0 0
SP081 LMCA Fixed control constant
Set by Mitsubishi.
Set "14" unless designated in particular.
14 14
SP082 LMCB Fixed control constant Set by Mitsubishi. Set "0" unless designated in particular. 0 0
SP083 Fixed control constant Set by Mitsubishi. Set "0" unless designated in particular. 0 0
SP084 Not used. Set "0". 0 0
Parameters with an asterisk * in the abbreviation, such as OSP*, are validated with the NC power turned ON again.
