3. Setup
3 - 28
High-gain specifications
No. Abbrev. Parameter name Explanation
Setting range
(Unit)
8
9
A
ent
B
Set the detector type.
Set the position detector type for "pen", and the speed detector type
for "ent". In the case of the semi-closed loop control, set the same
value for "pen" and "ent".
C Detector model name pen setting ent setting
D OSE104 0 (Note) 0
E
pen
OSA104 1 (Note) 1
F OSE105, OSA105 2 (Note) 2
3 (Note) 3
OHE25K-ET, OSE104-ET 4 Setting impossible
OHA25K-ET, OSA104-ET 5 Setting impossible
OSE105-ET, OSA105-ET, RCN223,
RCN723 (Heidenhain)
6 Setting impossible
7 Setting impossible
Relative position detection scale, MP
type (Mitsubishi Heavy Industries)
8 Setting impossible
AT41 (Mitsutoyo), FME type, FLE type
(Futaba)
9 Setting impossible
AT342, AT343, AT543 (Mitsutoyo),
LC191M/491M (Heidenhain),
MDS-B-HR
A Setting impossible
B Setting impossible
The setting of the slave axis in the
speed/current synchronization control.
When the master axis is the
semi-closed control.
C
C
(Current
synchronization)
The setting of the slave axis in the
speed/ current synchronization control.
When the master axis is the full-closed
control.
(Current synchronization control is only
for MDS-C1-V2.)
D
E
(Current
synchronization)
E Setting impossible
F Setting impossible
(Note) Setting for semi-closed loop control
SV025 MTYP*
Motor/Detector
type
SV026 OD2
Excessive error
detection width
during servo OFF
Set the excessive error detection width when servo ON.
For the standard setting, refer to the explanation of SV023 (OD1).
When "0" is set, the excessive error detection will not be performed.
0 to 32767
(mm)
Parameters with an asterisk * in the abbreviation, such as PC1*, are validated with the NC power turned ON again.
