3. Setup
3 - 96
No. Abbr. Parameter name Details
<For MDS-C1-SP/SPH/SPX/SPHX>
FEDCBA98765 4 3 2 10
odx8 phos fdir pyfx rtrn adin fclx
bit Meaning when set to 0 Meaning when set to 1 Standard
0 fclx Closed loop Semi-closed loop 0
1 adin
Interpolation A/D compensation
invalid
Interpolation A/D compensation
valid
0
2rtrn
Position monitor during ready OFF
invalid
Position monitor during ready OFF
valid
0
3 pyfx Normal excitation
Position loop excitation fixed
(strong)
0
4 0
5fdir
Position detector direc-
tion (positive direction)
Position detector direc-
tion (negative direction)
0
6 0
7 0
8 phos
High-gain servo synchronous
compensation invalid
High-gain servo synchronous
compensation valid
0
9 0
A 0
B 0
C 0
D odx8
Excessive error detection width
normal
Magnification of excessive error
detection width × 8 times valid
0
E 0
F 0
SP177 SPECS*
Spindle synchronous
specifications
(Note 1) bits 5, D and F are invalid for SPX and SPHX. Set the direction with
SP097.
(Note 2) Set 0 if there is no particular explanation for the bit.
<For MDS-C1-SPM>
FEDCBA98765 4 3 2 10
odx8 phos fdir
mach
fclx
bit Meaning when set to 0 Meaning when set to 1 Standard
0 fclx Closed loop Semi-closed loop 0
1 0
2 0
3mach
Automatic coil changeover during
spindle synchronization invalid
Automatic coil changeover during
spindle synchronization valid
0
4 0
5fdir
Position detector direction
(positive direction)
Position detector direction
(negative direction)
0
6 0
7 0
8 phos
High-gain servo synchronous
compensation invalid
High-gain servo synchronous
compensation valid
1
9 0
A 0
B 0
C 0
D odx8
Excessive error detection width
normal
Magnification of excessive error
detection width × 8 times valid
0
E 0
F 0
(Note) Set 0 if there is no particular explanation for the bit.
Parameters with an asterisk * in the abbreviation, such as OSP*, are validated with the NC power turned ON again.
