3. Setup
3 - 77
No. Abbr. Parameter name Details
<For MDS-C1-SP/SPH>
FEDCBA98765 4 3 2 10
splg dplg ospcl
noplg
nsno nosg plgo
mago
enco
bit Meaning when set to 0 Meaning when set to 1 Standard
0 enco Encoder orientation invalid Encoder orientation valid 0
1 mago Magnetic sensor orientation invalid Magnetic sensor orientation valid 0
2 plgo PLG orientation invalid PLG orientation valid 0
3 0
4 0
5 0
6 0
7 0
8 nosg
No-signal detection type
(Always monitoring)
No-signal detection valid only in
position loop or orientation-mode
0
9 nsno No-signal detection valid No-signal detection invalid 0
A noplg
Constant monitor of PLG-Z phase
no-signal invalid
Constant monitor of PLG-Z phase
no-signal valid
0
B 0
C 0
D ospcl
Orientation speed clamp
motor speed setting
Orientation speed clamp
spindle speed setting
0
E dplg 0
Fsplg
This is used by Mitsubishi. Set to "0" unless particularly designated.
0
(Note 1) For bit0 to 2, do not set two bits or more to "1" at the same time.
(Note 2) BitD is valid only when MDS-C1-SPH is used.
(Note 3) Set 0 if there is no particular explanation for the bit.
SP037 SFNC5* Spindle function 5
<For MDS-C1-SPX/SPHX>
FEDCBA98765 4 3 2 10
enco
bit Meaning when set to 0 Meaning when set to 1 Standard
0 enco Spindle end PLG orientation invalid Spindle end PLG orientation valid 0
1 0
2 0
3 0
4 0
5 0
6 0
7 0
8 0
9 0
A 0
B 0
C 0
D 0
E 0
F 0
(Note) Set 0 if there is no particular explanation for the bit.
Parameters with an asterisk * in the abbreviation, such as OSP*, are validated with the NC power turned ON again.
