5. Spindle Adjustment
5 - 34
(8) Adjusting excitation rate
If the motor noise is excessive during constant-speed operation, adjust the variable excitation
(SP056) value downward in decrements of 10 from the standard setting of 50 (setting lower limit =
25). The SP033/bit9 parameter setting is an effective way to reduce noise for high-speed operation
only (it lowers the excitation rate for high-speed operation only).
No. Abbr. Parameter name Details
Setting
range
Standard
SP056 PYVR Variable excitation
(min value)
Set the minimum value of the variable excitation rate.
Select a smaller value when gear noise is too high.
Larger value is more effective on impact response.
0 to 100
(%)
50
<For MDS-C1-SP/SPH/SPX/SPHX>
F EDCBA98765 4 3 2 10
poff hzs ront pycal pychg pyst pyoff sftk dflt 1a2m
bit Meaning when set to 0 Meaning when set to 1
Standard
9 pycal
(Conventional specifications) High-speed rate deceleration
method valid for minimum
excitation rate
0
SP033 SFNC1* Spindle function 1
