2. Wiring and Connection
2 - 29
(2) Connecting the magnetic sensor
Refer to section (1) for connection with the spindle motor.
Name
P15(+15V)
MAG
LS
Pin
1
2
3
4
5
6
7
8
9
10
MDS-C1-SP
Option cable : CNP6M
Option cable : CNP5
U VW
U V W
CN5
Spindle motor
Magnetic sensor
Power cable
Max. 30m
CN6
Spindle
Pin No.
Detector connector : CN6
No.1
No.10
No.11
No.20
Name
LG
MAGR
LSR
Pin
11
12
13
14
15
16
17
18
19
20
CAUTION
The shield of spindle detector cable is not FG. Do not ground.
