5. Spindle Adjustment
5 - 39
Default parameter settings for detector in use
No. Abbr. Parameter name
(a) Motor PLG (b) Spindle detector
(c) Magnetic
sensor
SP126 MPGM Orientation position loop gain M coil magnification 0 0 0
SP127 MPCSM Orientation deceleration rate M coil magnification 0 0 0
SP128 OXKPM
After orientation completion,
Position loop gain magnification
(M coil)
0 0 0
SP225 OXKPH
Position loop gain magnification after orientation
completed (H coil)
0 0 0
SP226 OXKPL
Position loop gain magnification after orientation
completed (L coil)
0 0 0
SP227 OXVKP
Speed loop proportional gain magnification after
orientation completed
0 0 0
SP228 OXVKI
Speed loop cumulative gain magnification after
orientation completed
0 0 0
(Note 1) *: Set according to machine specifications, -: Setting irrelevant
(Note 2) Parameters with an asterisk in the Abbrev. column (such as OSP*) are validated when the NC power is turned ON
again.
