3. Setup
3 - 102
No. Abbr. Parameter name Details
Setting range
(Unit)
Standard
setting
<For MDS-C1-SP/SPH/SPM>
This validates the automatic adjustment function for the
PLG.
0 to 1
0 → 1
SP245 PGHS
PLG automatic
adjustment
<For MDS-C1-SPX/SPHX>
Not used. Set "0".
0 0
SP246 TEST Fixed control constant Set by Mitsubishi. Set "0" unless designated in particular. 0 0
SP247 Not used. Set "0". 0 0
SP248 Not used. Set "0". 0 0
SP249 SMO Speed meter speed
Set the motor rotation speed when the speed meter 10V
is output.
When set to "0", this parameter becomes the same as
SP017 (TSP).
0 to 32767
(r/min)
0
SP250 LMO Load meter voltage
Set the voltage when the load meter 120% is output.
When set to "0", this becomes 10V.
0 to 10 (V) 0
SP251 Not used. Set "0". 0 0
SP252 Not used. Set "0". 0 0
SP253 DA1NO
D/A output channel 1
data number
Set the output data number for channel 1 of the D/A
output function.
When set to "0", the output is speedometer.
-32768 to
32767
0
SP254 DA2NO
D/A output channel 2
data number
Set the output data number for channel 2 of the D/A
output function.
When set to "0", the output is speedometer.
-32768 to
32767
0
SP255 DA1MPY
DA output channel 1
magnification
Set the data magnification for channel 1 of the D/A output
function.
The output magnification is the setting value divided by
256.
When set to "0", the output magnification becomes 1-fold,
in the same manner as when "256" is set.
-32768 to
32767
(1/256-fold)
0
SP256 DA2MPY
DA output channel 2
magnification
Set the data magnification for channel 2 of the D/A output
function.
The output magnification is the setting value divided by
256.
When set to "0", the output magnification becomes 1-fold,
in the same manner as when "256" is set.
-32768 to
32767
(1/256-fold)
0
Parameters with an asterisk * in the abbreviation, such as OSP*, are validated with the NC power turned ON again.
