Appendix 1. Cable and Connector Specifications
A1 - 13
Connectors for detector and motor power (IP67 and EN standard compatible)
Straight plug
Manufacturer: DDK (Ltd.)
D or less
7.85 or more
W
A
øC
±
0.8
-0.38
+0
øB
[Unit: mm]
Type A B C±0.8
D or less
W
CE05-6A18-12SD-B-BSS
1
1
/
8
-18UNEF-2B 34.13 32.1 57 1-20UNEF-2A
CE05-6A22-23SD-B-BSS
1
3
/
8
-18UNEF-2B 40.48 38.3 61 1
3
/
16
-18UNEF-2A
CE05-6A24-10SD-B-BSS
1
1
/
2
-18UNEF-2B 43.63 42.0 68 1
7
/
16
-18UNEF-2A
CE05-6A32-17SD-B-BSS
2-18UNS-2B 56.33 54.2 79 1
3
/
4
-18UNS-2A
Angle plug
Manufacturer: DDK (Ltd.)
D or less
R
±
0.7 U
±
0.7
(S)
±
1
Y or more
W
A
-0.38
+0
ø B
[Unit: mm]
Type A B D or less W R±0.7 U±0.7 (S) ±1
Y or
more
CE05-8A18-12SD-B-BAS
1
1
/
8
-18UNEF-2B 34.13 69.5 1-20UNEF-2A 13.2 30.2 43.4 7.5
CE05-8A22-23SD-B-BAS
1
3
/
8
-18UNEF-2B 40.48 75.5 1
3
/
16
-18UNEF-2A 16.3 33.3 49.6 7.5
CE05-8A24-10SD-B-BAS
1
1
/
2
-18UNEF-2B 43.63 86.3 1
7
/
16
-18UNEF-2A 18.2 36.5 54.7 7.5
CE05-8A32-17SD-B-BAS
2-18UNS-2B 56.33 93.5 1
3
/
4
-18UNS-2A 24.6 44.5 61.9 8.5
Cable clamp
Manufacturer: DDK (Ltd.)
(Moveable range of one side)
øE
(Cable clamp inside
diameter
)
H
G
±
0.7
A
V screw
C
1.6
(Bushing inside
diameter)
øF
(D)
B
±
0.7
[Unit: mm]
Total
length
Outside
dia.
Effective
screw
length
Type
Shell
size
A B C D E F G H
Installation
screw
V
Bushing
Compliant
cable
CE3057-10A-2 (D265)
18 23.8 30.1 10.3 41.3 15.9 11 31.7 3.2 1-20UNEF-2B CE3420-10-2 ø8.5 to ø11
CE3057-12A-2 (D265)
20 13 CE3420-12-2 ø9.5 to ø13
CE3057-12A-3 (D265)
22
23.8 35 10.3 41.3 19
10
37.3 4 1
3
/
16
-18UNEF-2B
CE3420-12-3 ø6.8 to ø10
CE3057-16A-2 (D265)
24 26.2 42.1 10.3 41.3 23.8 15.5 42.9 4.8 1
7
/
16
-18UNEF-2B CE3420-16-2 ø13 to ø15.5
CE3057-20A-1 (D265)
32 27.8 51.6 11.9 43.0 31.7 23.8 51.6 6.3
1
3
/
4
-18UNS-2B
CE3420-20-1 ø22 to ø23.8
+0
-0.38
+0
–0.38
