3. Setup
3 - 74
No. Abbr. Parameter name Details
<For MDS-C1-SP/SPH/SPX/SPHX>
FEDCBA98765 4 3 2 10
mkc2 mkch
invm mtsl
bit Meaning when set to 0 Meaning when set to 1 Standard
0 mtsl Special motor constant invalid Special motor constant setting valid 0
1invm
A general-purpose motor FV control
invalid
A general-purpose motor FV control
valid
0
2 mkch Coil switch function invalid Coil switch function valid 0
3 mkc2 Coil switch function 2 invalid
Coil switch function 2 valid
(Turns ON simultaneously with bit2)
0
4 0
5 0
6 0
7 0
8 0
9 0
A 0
B 0
C 0
D 0
E 0
F 0
(Note 1) To validate bit3, NC side needs to be prepared.
(Note 2) Set 0 if there is no particular explanation for the bit.
SP034 SFNC2* Spindle function 2
<For MDS-C1-SPM>
FEDCBA98765 4 3 2 10
mkc2 mkch mk3c
mtsl
bit Meaning when set to 0 Meaning when set to 1 Standard
0 mtsl Special motor constant invalid Special motor constant setting valid 0
1 mk3c 3-step coil switch function invalid 3-step coil switch function valid 0
2 mkch Coil switch function invalid Coil switch function valid 0
3 mkc2 Coil switch function 2 invalid
Coil switch function 2 valid
(Turns ON simultaneously with bit2)
0
4 0
5 0
6 0
7 0
8 0
9 0
A 0
B 0
C 0
D 0
E 0
F 0
(Note 1) To validate bit3, NC side needs to be prepared.
(Note 2) Set 0 if there is no particular explanation for the bit.
Parameters with an asterisk * in the abbreviation, such as OSP*, are validated with the NC power turned ON again.
