5. Spindle Adjustment
5 - 11
bitA. Indexing forward run command (WRN)
bitB. Indexing reverse run command (WRI)
This is valid when the orientation start command is ON.
WRI WRN Explanation
1
(ON)
1
(ON)
Setting prohibited.
0
(OFF)
1
(ON)
Indexing is carried out in the counterclockwise (CCW)
direction looking from the motor end.
1
(ON)
0
(OFF)
Indexing is carried out in the clockwise (CW) direction
looking from the motor end.
0
(OFF)
0
(OFF)
Indexing is not carried out.
bitC. Orientation start command (ORC)
This signal is used to start orientation. Orientation has a priority when the orientation start
command is input.
ORC Explanation
1 (ON) Orientation starts regardless of the run command (SRN, SRI).
0 (OFF)
When a run command (SRN, SRI) is selected, the rotation starts again
at the commanded speed.
bitD. L coil selection command (LCS)
This command is input to select the coil method for changing the coil. Note that coil changeover is
not possible when orientation is commanded. The coil is fixed when the orientation command is
input.
LCS Explanation
1 (ON) The low-speed command is selected.
0 (OFF) The high-speed command is selected.
