Appendix 1. Cable and Connector Specifications
A1 - 14
Connectors for detector, motor power and brake (IP67 and EN standard compatible)
Straight plug
Manufacturer: DDK (Ltd.)
-0.25
+0.05
øG
J
±
0.12
E±0.3
C±0.5
Gasket
D
H or less
A
-0.38
+0
øB
[Unit: mm]
Type A B C±0.5 D E±0.3 G J±0.12
MS3106A10SL-4S (D190)
5
/
8
-24UNEF-2B 22.22 23.3
9
/
16
-24UNEF-2A 7.5 12.5 13.49
MS3106A22-14S (D190)
1
3
/
8
-18UNEF-2B 40.48 34.11 1
1
/
4
-18UNEF-2A 12.15 29.9 18.26
Straight back shell
Manufacturer: DDK (Ltd.)
W screw
øC
øA
L
B
V screw
O-ring
7.85 or more
(Effective screw length)
D
(Spanner grip)
[Unit: mm]
Type L A B C D V W
CE02-22BS-S
35 36.5 10.9 17.8 32.4 1
1
/
4
-18UNEF-2B 1
3
/
16
-18UNEF-2A
Angle back shell
Manufacturer: DDK (Ltd.)
Type: CE-22BA-S
[Unit: mm]
ø38.6
50.5 or less
39.6 or less
16.3
(49.6)
7.5 or more
33.3
1
1
/
4
-18UNEF-2B screw
1
3
/
16
-18UNEF-2A screw
O-ring
