3. Setup
3 - 78
No. Abbr. Parameter name Details
<For MDS-C1-SPM>
FEDCBA98765 4 3 2 10
nsno nosg plgo
enco
bit Meaning when set to 0 Meaning when set to 1 Standard
0 enco Encoder orientation invalid Encoder orientation valid 0
1 0
2 plgo PLG orientation invalid PLG orientation valid 0
3 0
4 0
SP037 SFNC5* Spindle function 5
5 0
6 0
7 0
8 nosg
No-signal detection type
(Always monitoring)
Monitoring only in position loop or
orientation-mode
0
9 nsno No-signal detection valid No-signal detection invalid 0
A 0
B 0
C 0
D 0
E 0
F 0
(Note 1) For bit0 to 2, do not set two bits or more to "1" at the same time.
(Note 2) Set 0 if there is no particular explanation for the bit.
Parameters with an asterisk * in the abbreviation, such as OSP*, are validated with the NC power turned ON again.
