Appendix 1. Cable and Connector Specifications
A1 - 12
Appendix 1-3 Connector outline dimension drawings
Connector for CN2 Servo drive unit
Manufacturer: 3M (Ltd.)
<Type>
Connector: 10120-3000VE
Shell kit: 10320-52F0-008
[Unit: mm]
22.0
39.0
33.3
12.7
14.0
23.8
12.0
10.0
Manufacturer: 3M (Ltd.)
<Type>
Connector: 10120-3000VE
Shell kit: 10320-52A0-008
[Unit: mm]
22.0
3
9
.
0
33.3
2
3
.
8
12.7
14.0
12.0
1
0
.
0
Manufacturer: 3M (Ltd.)
<Type>
Connector: 10120-6000EL
Shell kit: 10320-3210-000
Because this connector is an
integrated molding part of the cable,
it is not an option setting in the
connector set.
The terminal connector (A-TM) also
has the same outline.
[Unit: mm]
20.9
29.7
33.0
42.0
11.5
22.0
14.0
12.0
33.3
12.7
39.0
23.8
10.0
12.0
10.0
14.0
22.0
33.3
12.7
23.8
39.0
11.5
42.0
33.0
20.9
29.7
