3. Setup
3 - 53
Standard specifications
No. Abbrev. Parameter name Explanation
Setting
range (Unit)
FEDCB A 98765 4 3 2 10
mpt mp abs vdir fdir
s
pw
v
seqh dfbx
bit Meaning when “0” is set Meaning when “1” is set
0
1 dfbx Dual feedback control stop Dual feedback control start
2 seqh
Normal ready ON/servo ON time High-speed ready ON/servo ON
time
3spwv
Normal mode High-gain servo synchronization
mode
4fdir
Position feedback forward
polarity
Position feedback reverse polarity
5vdir
Standard setting HA motor (4 pole motor)
Detector installation position 90
degrees (B, D)
6
7 abs Incremental control Absolute position control
8 mp MP scale 360P (2mm pitch) MP scale 720P (1mm pitch)
9mpt
MP scale ABS detection NC
control
MP scale ABS detection
automatic (Standard swetting)
A
B
C
D
E
F
SV017 SPEC*
Servo specification
selection
(Note) Set to “0” for bits with no particular description.
SV018 PIT* Ball screw pitch
Set the ball screw pitch. Set to “360” for the rotary axis.
1 to 32767
(mm/rev)
Parameters with an asterisk * in the abbreviation, such as PC1*, are validated with the NC power turned ON again.
