Appendix 2. Compliance to EC Directives
A2 - 5
(7) Peripheral devices
[1] Use EN/IEC Standards compliant parts for the no-fuse breaker and contactor.
(8) Miscellaneous
[1] Refer to "MDS-C1 INSTRUCTION MANUAL" for methods on complying with the EMC
Directives.
[2] Ground the facility according to each country's requirements.
[3] The control circuit connector ({) is safely separated from the main circuit (
).
[4] Inspect the appearance before installing the unit. Carry out a performance inspection of the
final unit, and save the inspection records.
MC1
Mitsubishi CNC
SV1, 2
(CSH21)
External emergency
stop input
T
S
R
Contactor No-fuse
breaker
Ground
: Main circuit
: Control circuit
CN1A
CN23
CN4
CN9
CN20
L1
L2
L3
L11 TE3
TE1
CN9
CN1B
L+
L-
MU
MV
MW
CN2L
CN2M
LU
LV
LW
TE1
Motor end
detector
Motor end
detector
MDS-A-BT-
MDS-C1-V2-
MDS-C1-CV-
Motor
Motor
CN4
Machine end
detector
Machine end
detector
TE3
TE2
L+
L-
L11
L21
TE2
A
C reactor
Ground
Ground
L21
CN3M
CN3L
MC
External brake
output contact
