3. Tool Offset (L system)
3.5 Tool Life Management II
I-104
Refer to "3 (II). Tool Offset (M system)" for M system.
(2) Registration group list screen
The life management data of the tool currently being used and the list of registered groups of tools are
displayed. This page is mainly used for monitoring tool life data in group units.
T-OFSET T-DATA NOSE-R LIFE MENU
[TOOL LIFE] TOOL 4. 2/5
<CHOSEN TOOL>
GROUP TOOL NO. COMP.NO. FORM USED TOTAL LIFE ST
1234 123456 12 0 123456 123456 999999(MIN) 1
<GROUP LIST>
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
91 92 93 94 95 96 97 98 99 100 101 102 103 104 105 106
111 222 333 444 555 666 777 888 999 1001 1101 1202 1303 1404 1505 1606
1100 2200 3300 4400 5500 6600 7700 8800 9900 1010 1111 1212 1313 1414 1515 1616
1234 2222 3333 4444 5555 6666 7777 8888 9999
1) Display details
< CHOSEN TOOL >: The life management information of the tool currently being used
appears here.
FORM : The incrementation unit of the life data appears here.
0: Time 1: Count
ST : The tool status appears here.
0: Not used tool 1: Current tool (tool being used)
2: Normal life-reached tool 3: Tool skip tool
TOTAL : For tools using multiple compensation Nos., the total of the usage
data for each compensation No. appears here. If there is only one
compensation No., the data will be the same as "USED".
< GROUP LIST > : All registered group Nos. appear here.
A highlighted group No. indicates that the lives of all tools registered in that
group have been reached.
2) Erasing all registered data of a group
All registered data (including the group No.) of a group can be erased by pressing
SHIFT
+
C.B
CAN
+
INPUT
keys.
3.5.2 Tool Life Incrementation Methods
The tool life can be incremented either by time method or by the No. of uses (count) method. The count
method and timing for the No. of uses (count) method can be changed to type 2 with the parameter setting
(#1277 ext13/bit0).
If the USED data equals or exceeds the LIFE data as a result of incrementation, a spare tool will be selected
from that tool's group by the next relevant group selection command (T****99). After that, the
incrementation will be for the newly selected tool (the spare tool selected). If the life of all tools in a group is
reached, and a spare tool cannot be selected, the incrementation will continue for the last tool selected.
