8. Maintenance Functions
8.1 Data Input/Output Function
III-69
(5) Example of data input operation
Confirm that the user PLC is
stopped.
Connect the input device.
Call out the data input screen, and
enter the compare mode.
# (10) data ( 2)
INPUT
1) The compare mode is canceled when
the screen is changed, and the input
mode will be validated. Thus, the
mode must be set again.
Set 9 9 in # setting area.
# (99) DATA ( )
<INPUT DATA>
N2L10001LF0000L0L0;
<COMP. DATA>
N2L10001LF0000L0L0;
COMPARE EXECUTION
#
(
9 9
)
DATA
(
101
)
<INPUT DATA>
%
<COMP. DATA>
%
COMPARE COMPLETE
#
(
)
DATA
(
)
1) The compare will start, and the
data being compared and
"COMPARE EXECUTION"
message will display.
The No. of the data will display
in the data setting area.
2) When the data is compared
normally to the end and the
end code % (EOR) is read in,
the message "COMPARE
COM-PLETE" will display.
3) If a compare error occurs, the
message "E35 COMPARE
ERROR" will display, and the
operation will be stopped.
Press
INPUT
key.
<INPUT DATA>
<COMP. DATA>
#
(
9 9
)
DATA
(
)
