2. Monitor
2.5 Resuming the Program
I-56
Display item Details
O 31000 N 1- 2
<SUB> O N -
This displays the restart searched position (program No., sequence No.,
block No.). If a subprogram is searched, those numbers also display.
[RESTART- (G54)]
X -130.000
Y -10.000
Z 0.000
C 0.000
This displays the remaining distance when the restart search is
completed.
[RESTART-R]
X -130.000
Y -10.000
Z 0.000
C 0.000
This displays the position on the local coordinate system when the restart
search is completed.
N6 Y-70.;
N7 X-20.;
This displays two blocks of the restart searched program.
O( )
N( )
-( )
<Setting range>
1 to 99999999
0 to 99999
0 to 99
These set the program number, sequence number
and block number to be searched.
For type A, the program No. cannot be omitted.
For type B, the program No. cannot be input.
P( )
0 to 9999 This sets the number of times the search block
appears. When, for instance, a block in the
subprogram is to be searched, the search block will be
executed a multiple number of times when that
subprogram is called for a similar number of times,
and so the number of times the block is to be executed
is set here.
There is no need to set this when a one-time
execution is to be searched or when the search block
is to be executed only once.
If 0 is set, a one-time execution is searched.
0 This designates an unmodal search.
1 This designates a type 1 restart search.
2 This designates a type 2 restart search.
T( )
3 This designates a type 3 restart search.
(This designates T command restart.)
0 This designates memory search. M( )
1 This designates tape search.
T-SELECT T
S-SPEED S1
S-SPEED S2
2nd AUX B
AUX M
This displays the tool command value.
This displays the 1st spindle rotation speed command value.
This displays the 2nd spindle rotation speed command value.
This displays the last four digits of the 2nd miscellaneous function
command value.
This displays the last four digits of the miscellaneous function command.
