1. Setting and Display Unit Operation
1.5 Data Setting Method
I-15
5) Data in parentheses where the cursor exists is erased by pressing the
C.B
CAN
key.
Display is made in the setting area as
shown in the right.
# ( 10) DATA ( 12.345)
If you press the
C.B
CAN
key,
# ( 10) DATA ( )
6) Data in all parentheses in the setting area is erased by pressing
SHIFT
C.B
CAN
.
Display is made in the setting area as
shown in the right.
If you press
SHIFT
C.B
CAN
,
# ( 10) DATA ( 12.345)
# ( ) DATA ( )
7) The cursor in parentheses is moved one column to the left or right by pressing the
or
key
desired character of data entered by using the data keys can be corrected.
Display is made in the setting area as
shown in the right.
If you make successive four strokes of
the
key,
If you press
3
,
# ( 10) DATA ( 12.345)
# ( 10) DATA ( 12.345)
# ( 10) DATA ( 13.345)
2 is corrected to 3 and the cursor is moved one column to the right.
If you press the
key,
# ( 10) DATA ( 13.345)
The cursor is only moved one column to the right.
If you press
0
SP
0
SP
0
SP
,
# ( 10) DATA ( 13.000)
The character at the cursor position is rewritten and the cursor is also moved one column to the right.
Data is corrected in sequence.
(Note 1)
If
is pressed when the cursor exists in the right end within one parenthesis, the cursor
is moved to the right end within the following parenthesis part; if
is pressed when the
cursor exists in the left end within one parenthesis, the cursor is moved to the right end
within the preceding parentheses.
