2. Monitor
2.4 PROGRAM SEARCH
I-50
(Note 3) When using the 2-part system, the method for calling the program No., sequence No. and block
No. for automatic operation can be switched with the parameters.
#1050
MemPrg
#1285
ext21/bit1
Details
0, 2, 4, 6 - Selected system: The machining program registered in the memory
common for the systems is called with the designated
program No., sequence No. and block No.
System that is not selected: The called machining program is held.
1, 3, 5, 7 OFF Selected system: The machining program registered in the memory for the
selected system is called with the designated program
No., sequence No. and block No.
System that is not selected: The called machining program is held.
ON Selected system: The machining program registered in the memory for the
selected system is called with the designated program
No., sequence No. and block No.
System that is not selected: The machining program registered in the
memory for each system is called with the
designated program No.
(Note 4) When using the 2-part system and the same number batch search for all system programs is
valid, the presence of machining programs for each system is searched for in the memory in the
following manner.
Presence of program
System 1 System 2
Operation
Yes Yes
Memory search is carried out simultaneously for the System 1 and
System 2 machining programs.
Yes No
Memory search is carried out for the System 1 machining program, and
then an error (E14) occurs.
No Yes
Memory search is carried out for the System 2 machining program, and
then an error (E14) occurs.
No No An error (E14) occurs.
