8. Maintenance Functions
8.2 Data Sampling
III-78
(12) #23 VARIABLE NO. (Setting range: 0 to 999)
Set the variable No. that causes the start/end trigger.
0: System variable (#1299)
Other than 0: Designated common variable (#100 ~, #500 ~)
(Note 1) If both #5 and #22 are set to a value other than "1" (variable No.), the value will be ignored even
if set.
(Note 2) If a number that does not exist is set, "E02 DATA OVER" will occur.
(13) #24 PLC DEVICE
(Setting range: For PLC4B : ~ (∗) X04BF, ~ (∗) Y053F, ~ (∗) U0017F, ~ (∗) W01FF
For GPPW : ~ (∗) X063F, ~ (∗) Y073F)
Set the PLC device that functions as the start/end trigger. If a "∗" is added at the head, the device will be
a b contact.
0: Data sampling trigger signal (Y2FC)
Other than 0: Designated device
(Note 1) If both #5 and #22 are set to a value other than "2" (PLC device), the value will be ignored even
if set.
(Note 2) If a device that does not exist is input, "E01 SETTING ERROR" will occur, and if the device No.
is not within the setting range, "E02 DATA OVER" will occur.
(14) #25 ADDRESS (For simple setup: 0)
Set the address targeted for applying #27 data mask.
However, if an illegal address (highest-order bit 0) is input, a setting error will occur.
If an address that does not exist is set, the system could fail.
(Note) If both #5 and #22 are set to a value other than "3" or "4" (address conditions, true/false), the
value will be ignored even if set. This item can be set with the same methods as #11 to #18.
(15) #26 DATA (For simple setup: 0)
Set the data for judging the results of applying #27 data mask on #25 address.
(Note) If both #5 and #22 are set to a value other than "3" or "4" (address conditions, true/false), the
value will be ignored even if set.
(16) #27 DATA MASK (For simple setup: 0)
Set the data mask to be applied on #25 address.
(Note) If both #5 and #22 are set to a value other than "3" or "4" (address conditions, true/false), the
value will be ignored even if set.
