2. Monitor
2.2 COORDINATE
I-33
(3) Operation method
During a single block stop or when a program error stop occurs, the buffer can be corrected with the
following operations, and operation can be continued.
(a)
(b)
* Buffer correction area (39 characters × 6 lines)
The normally executed program appears in this area. (Up to six lines will be displayed.)
←
Commands before previous command
←
Previous command
←
Command in execution
←
Next command and subsequent commands
:
:
N122 T1212;
N123 S1230 M3;
N124 G00 X68. Y201.;
N125 G01 X80. Y195. F50;
N126 Y150.;
N127 G02 X100. Y185. R20.;
:
:
[Buffer correction area in normal state]
Display
area
When correcting the buffer, the display changes so that the next command is displayed at the
head of the area, and the entire buffer correction area is highlighted. The cursor will initially
flicker at the head of the next command. The cursor can be moved freely within the buffer
correction area using the cursor keys. (6 lines)
N123 S1230 M3;
N124 G00 X68. Y201.;
N125 G01 X80. Y195. F50;
N126 Y150.;
N127 G02 X100. Y185. R20.;
N128 G01 X110.;
←
Next command and subsequent commands
[Buffer correction area during buffer correction]
Select the first page of the
COORDINATE screen.
Press the one of the cursor
keys (
,
,
,
) or tab
keys (
,
).
The buffer correction mode will be
entered, and the buffer correction area
will be highlighted.
