4. Parameters (User)
4.3 I/O Parameters
I-167
# Item Contents Setup range (unit)
9615 CTRL. CODE OUT Bit 0: NAK output
Specify whether to send the NAK code to the host
if a communication error occurs in computer link
B.
Bit 1: SYN output
Specify whether to send the SYN code to the host
if NC resetting or an emergency stop occurs in
computer link B.
Bit 3: DC3 output
Specify whether to send the DC3 code to the host
when communication ends in computer link B.
0: Do not output the
NAK code.
1: Output the NAK
code.
0: Do not output the
SYN code.
1: Output the SYN
code.
0: Do not output the
DC3 code.
1: Output the DC3
code.
9615
CTRL. CODE OUT Bit 0: NAK output
Specify whether to send the NAK code to the
host if a communication error occurs in computer
link B.
Bit 1: SYN output
Specify whether to send the SYN code to the
host if NC resetting or an emergency stop occurs
in computer link B.
Bit 3: DC3 output
Specify whether to send the DC3 code to the
host when communication ends in computer link
B.
0: Do not output the
NAK code.
1: Output the NAK
code.
0: Do not output the
SYN code.
1: Output the SYN
code.
0: Do not output the
DC3 code.
1: Output the DC3
code.
9616
CTRL. INTERVAL Not used
9617
WAIT TIME Not used
9618
PACKET LENGTH Not used
9619
BUFFER SIZE Not used
9620
START SIZE Not used
9621
DC1 OUT SIZE Not used
9622
POLLING TIMER Not used
9623
TRANS. WAIT TMR Not used
9624
RETRY COUNTER Not used
