3. Tool Offset (M system)
3.1 Tool Offset
I
-119
Refer to "3 (I). Tool Offset (L system)" for L system.
3.1.5 Manual Numeric Command Operation on the TOOL OFFSET Screen (M, T)
To execute a manual numeric command on the TOOL OFFSET screen, first change the mode from usual
data setting to manual numeric command. The M and T commands can be executed by screen operation in
manual numeric command mode.
(1) Changing the mode from usual data setting to manual
numeric command
In the usual data setting mode, the cursor is
displayed in the data setting field.
It is not displayed in manual numeric command
mode. By checking this difference, make sure that
the mode has changed. Change the mode by the
following operations:
T M
#( )DATA( )
Set
M
(Manual) in the first
parenthesis pair of the setting field.
T M
#( M )DATA( )
1) This operation is necessary regardless of the
command (M, T).
Press the
INPUT
key. The mode
changes to manual numerical
command.
T M
#( )DATA( )
1) Data is cleared from the setting field. The cursor is
also cleared from the screen.
(2) Execution the manual numeric command ... Execute this after operation (1) above.
1) Press the address key corresponding to the command. The corresponding command value display
field is highlighted, and the manual numeric command input mode is activated. To execute the tool
function, input
T
. To execute the miscellaneous function, input
M
.
2) Input the specified numerics from keys.
3) Press the
INPUT
key. The command is executed.
(Note)
The manual numeric command operation is the same as the operation for the POSITION screen.
See "Manual numeric Command" in 'POSITION' of 'MONITOR' screen for details.
(3) Returning the mode from manual numeric command to usual data setting
Press the
key. The usual data
setting mode returns.
T20 M6
#( )DATA( )
1) The cursor is displayed in first parenthesis pairs.
After this, usual data setting is enabled.
