4. Parameters (User)
4.3 I/O Parameters
I-162
4.3.2 I/O DEVICE PARAM
Parameters for up to five types of input/output devices can be set in DEV <0> to <4>.
[I/O DEVICE PARAM] DEV 0 PARAM 2.2/7
# # #
9101 DEVICE NAME - 9111 DC2/DC4 OUTPUT - 9121 EIA CODE [ -
9102 BAUD RATE - 9112 CR OUTPUT - 9122 ] -
9103 STOP BIT - 9113 EIA OUTPUT - 9123 # -
9104 PARITY CHECK - 9114 FEED CHR. - 9124
∗
-
9105 EVEN PARITY - 9115 PARITY V - 9125 = -
9106 CHR. LENGTH - 9116 TIME-OUT(sec) - 9126 : -
9107 TERMINATOR TYPE - 9117 DR OFF - 9127 $ -
9108 HAND SHAKE - 9118 DATA ASCII - 9128 ! -
9109 DC CODE PARITY - 9119 INPUT TYPE - 9129
9110 9120 9130
# ( ) DATA ( )
WORK PROCESS
I/O PAR SETUP MENU
# Item Contents Setup range (unit)
9101
DEVICE NAME Set the device name corresponding to the device
No.
Set a simple name for quick identification.
Use alphabet
characters‚ numerals
and symbols to set a
name within 3
characters.
9102
BAUD RATE Set the serial communication speed.
0: 19200 (bps)
1: 9600
2: 4800
3: 2400
4: 1200
5: 600
6: 300
7: 150
9103
STOP BIT Set the stop bit length used in the start-stop system.
1: 1 (bit)
2: 1.5
3: 2
9104
PARITY CHECK Specify whether to add the parity check bit to the
data during communication.
0: Parity bit not
added
1: Parity bit added
9105
EVEN PARITY Specify the odd or even parity when it is added to
the data.
0: Odd parity
1: Even parity
9106
CHR. LENGTH Set the length of the data bit. 0: 5 (bit)
1: 6
2: 7
3: 8
9107
TERMINATOR TYPE The code to terminate data reading can be selected. 0 and 3: EOR
1 and 2: EOB or
EOR
