2.5 Resuming the Program
The PROGRAM RESTART screen will open when the menu key
RESEARCH
is pressed.
RESERCH PLC-SW COM-VAR LOC-VAR MENU
[PROGRAM RESTART] MONITOR 5 .1/ 2
O 31000 N 1- 2
<SUB> O N -
[RESTART- (G54)] [RESTART-R]
X -130.000 X -130.000
Y -10.000 Y -10.000
Z 0.000 Z 0.000
C 0.000 C 0.000
N6 Y-70.;
N7 X-20.;
M: MODE <0>MEMORY <1>TAPE
T: TYPE <0>UNMODLE <1>TYPE 1 <2>TYPE 2
<3>T-TYP
O
( ) N( )-( )P( ) T( ) M( )
$1
[PROGRAM RESTART] MONITOR 5 .1/ 2
O 31000 N 1- 2
<SUB> O N -
T-SELECT T 10
S-SPEED S1 3000 2500 2000
S-SPEED S2 2000 3000 3500
2nd AUX B
AUX M 6 3 8
9 6
RESERCH PLC-SW COM-VAR LOC-VAR MENU
The program restart function is used to resume machining after the machining program has been stopped
midway. The program and block to be restarted are searched for, and machining is resumed from that
block.
The restart types include type 1, type 2 and type 3 (T command restart).
Restart method Details
Restart type 1 After machining is reset due to a tool breakage, etc., machining is restarted
from the designated sequence number and block number.
Restart type 2 After machining program is stopped due to a halt and the power is turned
OFF and ON, machining is restarted from the designated sequence number
and block number.
Restart type 3
(T command restart)
After the machining program is stopped due to tool breakage, etc., the T
command block executed last in the halted program is searched for and
machining is restarted from the next block.
(Note) Restart type 3 is valid only with the lathe system.
Restart type 1 and restart type 2 include types A and B.
Restart method Type Details
Type A The search is executed only in the machining program number
having the designated sequence number and block number. The
machining program number cannot be omitted.
Restart type 1/2
Type B The restart search is executed for the currently searched
machining program, so the machining program to be restart
searched cannot be input.
The designated sequence number and block number are
searched from all programs within the currently searched program
number. (Sequence number and block number in the subprogram
are searched when there are subprograms.)
