3. Tool Offset (M system)
3.2 Tool Registration
I
-123
Refer to "3 (I). Tool Offset (L system)" for L system.
3.2.5 Manual numeric Command Operation on the TOOL REGISTRATION Screen (M, T)
To execute a manual numeric command on the TOOL REGISTRATION screen, first change the mode from
usual data setting to manual numeric command. The M and T commands can be executed by screen
operation in manual numeric command mode.
(1) Changing the mode from usual data setting to manual numeric command
In the usual data setting mode, the cursor is
displayed in the data setting field. It is not
displayed in manual numeric command mode. By
checking this difference, make sure that the mode
has changed. Change the mode by the following
operations:
T M
MG( )TOOL( )D( )AUX( )
Set
M
(Manual) in the first
parenthesis pair of the setting field.
T M
MG( M )TOOL( )D( )AUX( )
1) This operation is necessary regardless of the
command (M, T).
Press the
INPUT
key. The mode
changes to manual numerical
command.
T M
MG( )TOOL( )D( )AUX( )
1) Data is cleared from the setting field. The cursor is
also cleared from the screen.
(2) Execution of the manual numeric command ... Execute this after operation (1) above.
1) Press the address key corresponding to the command. The corresponding command value display
field is highlighted, and the manual numeric command input mode is activated. To execute the tool
function, input
T
. To execute the miscellaneous function, input
M
.
2) Input the specified numerics from keys.
3) Press the
INPUT
key. The command is executed.
(Note)
The manual numeric command operation is the same as the operation for the POSITION screen.
See "2.1.3 Manual numeric Command" in 'POSITION' of 'MONITOR' screen for details.
(3) Returning the mode from manual numeric command to usual data setting
Press the
. The usual data setting
mode returns.
T20 M6
MG( )TOOL( )D( )AUX( )
1) The cursor is displayed in first parenthesis pairs.
After this, usual data setting is enabled.
