Appendix 4. Registering/Editing the Fixed Cycle Program
4.6 Standard Fixed Cycle Subprogram (For M system)
IV-16
Return.
Define the cutting amount for block 2 and after.
Cutting feed
Return.
G84 (O840) Tap cycle
Fixed cycle block 1 movement command
Check for fixed cycle invalidity.
Inhibit single block stop.
Invalidate feed hold/override.
Dwell.
Rotate the spindle reversely.
Dwell.
Rotate the spindle forward.
Return.
G85 (O850) Boring 1
Fixed cycle block 1 movement command
Check for fixed cycle invalidity.
Inhibit single block stop.
Return.
G0 Z#28 ;
#29 = #11 + #14 ;
END1 ;
N1 G1 Z#3 − #26 ;
#3003 = #8 ;
G0 Z − #3 − #2 ;
N2 M99%
G. 1 ;
1F [#30] GOTO1 ;
Z#2 G#6 H#7 ;
#2 = ##5
#3003 = #8 OR 1 ;
#3004 = #9 OR 3 ;
G1 Z#3 ;
G4 P#4 ;
M4 ;
#3900 = 1 ;
G1 Z − #3 ;
#3004 = #9 ;
G4 P#4 ;
M3 ;
#3003 = #8 ;
G0 Z = #2 ;
N1 M99%
G. 1 ;
1F [#30] GOTO1 ;
Z#2 G#6 H#7 ;
#2 = ##5
#3003 = #8 OR 1 ;
G1 Z#3 ;
#3003 = #8 ;
Z − #3 ;
G0 Z − #2 ;
N1 M99%
