3. Tool Offset (M system)
3.2 Tool Registration
I-122
Refer to "3 (I). Tool Offset (L system)" for L system.
3.2.3 Tool Registration in HEAD, NEXT, and INDEX
This function is used to change display data when the tool number set in magazine pot differs from the
displayed tool number.
Press the
INPUT
key.
Set SP in MG ( ), and
8 in TOOL ( ).
Set in HEAD MG (SP) TOOL ( )
Set in NEXT 1 MG (N1) TOOL ( )
Set in NEXT 2 MG (N2) TOOL ( )
Set in NEXT 3 MG (N3) TOOL ( )
Set in INDEX MG (N4) TOOL ( )
OFFSET REGIST LIFE MENU
[T-REGISTRATION] TOOL 2.1/2
HEAD NEXT-1 NEXT-2 NEXT-3 SEARCH
10 20 21 30 22
MG TOOL-D MG TOOL-D MG TOOL-D
1 101 0 11 201 0 21 301 0
2 102 0 12 202 0 22 302 0
3 103 0 13 203 0 23 303 0
4 104 0 14 204 0 24 304 0
5 105 0 15 205 0 25 305 0
6 106 0 16 206 0 26 306 0
7 107 0 17 207 0 27 307 0
8 108 0 18 208 0 28 308 0
9 109 0 19 209 0 29 309 0
10 110 0 20 210 0 30 310 0
T 0 M
MG( )
TOOL(
) D(
) AUX
( )
8 is displayed below HEAD in the data display area and a change is
made to MG (N1) in the data setting area.
(Note) Although the title display on the screen top (HEAD,NEXT 1 to NEXT 3, INDEX) varies depending on
the machine maker, data is set by using SP And N1 to N4.
3.2.4 Tool Registration Data Clear
Press the
INPUT
key.
A
ll data displayed in HEAD, NEXT 1
to NEXT 3, INDEX, and MG1 to MGn
is cleared.
Set CL in MG ( ).
(Note) If any other key has been pressed before the
INPUT
key is pressed, the tool registration data will
not be cleared.
