7. Diagnosis
7.3 SPINDLE MONITOR
I-283
Display item Explanation
Control output 3 Driver control output signal
F E DCBA9876543 2 1 0
In sub-motor selection
0:Main motor 2: Sub motor2
1:Sub motor1 3: Sub motor3
In L winding selection
In orient start
In index reverse run
In index forward run
In reverse run start
In forward run start
In gear selection
In spindle control mode selection
0: No. 1 gea
r
1: No. 2 gear
2: No. 3 gear
3: No. 4 gear
4: No. 5 gear
5: No. 6 gear
6: No. 7 gear
7: No. 8 gear
Control output 4 Driver control output signal
F E DCBA9876543 2 1 0
No.2 in-position
Orient completed
Zero speed detection
Speed reached
Speed detection
Current detection
