5. Stored Stroke Limit
5.2 Stored stroke limit II
III-31
5.2 Stored stroke limit II
The boundary is set with the parameters (axis parameters
#8204 OT-CHECK-N, #8205 OT-CHECK-P) or with the
program commands. Either the inside or the outside of the set boundary is the prohibited range. Whether the
inside or outside of the range is prohibited is determined by parameter (
#8210 OT-INSIDE). When the inside is
selected, this function is called stored stroke limit IIB.
When using program commands, entry of the tool into the prohibited range is prohibited with G22, and entry
into the prohibited range is enabled with G23.
The stored stroke limit II function can be invalidated for each axis with the parameter setting (
#8202 OT-CHECK
OFF: 1
).
"
#8210 OT-INSIDE" can be set for each axis, but when used in combination, the following type of operation is
possible.
X Z Movement prohibited range
Moveable range
Outside
Outside
Moveable range
Outside
Inside
Moveable range
Inside
Inside
Moveable range
