5. Program
5.7 Word Editing
I-204
When the bit is ON (menu type 2)
WORD↓ WORD↑ STR. ↓ STR. ↑
RETURN
Menu Function
SEARCH This changes the menu for selecting the search direction.
DELETE The word at the cursor position can be deleted.
(The deleted word is set in the EDIT BUFFER area.)
REPLACE The word at the cursor position can be replaced with the data in the EDIT
BUFFER area.
(The EDIT BUFFER area data is not cleared.)
INSERT
A
word in the EDIT BUFFER area can be inserted in the location immediately
after the word at the cursor position.
(The EDIT BUFFER area data is not cleared.)
COPY The word at the cursor position can be copied into the EDIT BUFFER area.
PROGRAM The menu changes to the one for searching the program. The searched
program and a list of programs are displayed.
COM. SRH The program Nos., sequence Nos., and block Nos. for carrying out automatic
operation can be searched from the machining programs registered in the
NC memory.
B.G SRH The program Nos. sequence Nos. and block Nos. for background editing can
be searched.
If a program No. not registered in the NC memory is set, a new machining
program will be registered.
B.G-END This quits the background editing function.
COMMENT An outline of the machining program functions, specifications, applications,
etc., can be set as a comment.
RETURN This returns to the top menu.
WORD↓
This searches in the downward direction. The word matching the search data
is searched, and the cursor moves to that word. (The search data is not
cleared.)
WORD↑
This searches in the upward direction. The word matching the search data is
searched, and the cursor moves to that word. (The search data is not
cleared.)
STR. ↓
This searches in the downward direction. The character string matching the
search data is searched, and the cursor moves to that word. (The search
data is not cleared.)
STR. ↑
This searches in the upward direction. The character string matching the
search data is searched, and the cursor moves to that word. (The search
data is not cleared.)
LOOK UP
PROGRAM
MENU
COPY DELETE REPLACE INSERT MENU
COM.SRH
B.G SRH B.G END
COMMENT
RETURN
