3. Tool Offset (L system)
3.6 Tool Registration
I-107
Refer to "3 (II). Tool Offset (M system)" for M system.
3.6 Tool Registration
The TOOL REGISTRATION screen will appear when the menu key
LIFE
is pressed, and the screen is
changed using the
NEXT
PAGE
key. The use of this screen differs according to the user PLC, so refer to the
instruction manual issued by the machine maker for details.
3.6.1 Outline of Functions
(1) Tools used can be registered in the magazine pot.
(2) When the magazine pot and the tool No. are changed by a tool selection command or a tool
replacement command, the new tool No. is displayed.
(3) Random data can be set in AUX ( ) in the setting area and processed as a sequence with the user PLC.
(4) Tools can be registered in USAGE on the upper portion of the screen. The displayed name and
displayed No. can be changed.
(5) The No. of tool registrations differs according to the specifications, but a max. of 80 tools can be
registered, with a max. of 4 digits in the tool Nos.
(6) Tools can be selected by a manual numeric command.
T-OFSET T-DATA NOSE-R LIFE MENU
[T-REGISTRATION] TOOL 2.1/2
HEAD NEXT-1 NEXT-2 NEXT-3 SEARCH
10 20 21 30 22
MG TOOL-D MG TOOL-D MG TOOL-D
1 101 0 11 201 0 21 301 0
2 102 0 12 202 0 22 302 0
3 103 0 13 203 0 23 303 0
4 104 0 14 204 0 24 304 0
5 105 0 15 205 0 25 305 0
6 106 0 16 206 0 26 306 0
7 107 0 17 207 0 27 307 0
8 108 0 18 208 0 28 308 0
9 109 0 19 209 0 29 309 0
10 110 0 20 210 0 30 310 0
T 0 M
MG( )
TOOL(
) D(
) AUX
( )
3.6.2 Tool Registration in the Magazine Pot
T-OFSET T-DATA NOSE-R LIFE MENU
T 0 M
MG( 1 )
TOOL(
1234
) D(
2
) AUX
( )
Set 1 in MG ( ),
1234 in TOOL ( ), and
2 in D ( ).
