4. Parameters (User)
4.2 Machining Parameters
I-146
4.2 Machining Parameters
Pressing the menu key
PROCESS
displays the PROCESS PARAMERTER screen.
The number of digits in the decimal section of the parameters related to length is determined by the input
setting unit.
The input setting unit is set with parameter "#1003 iunit".
Input setting unit No. of digits in decimal section Example of setting range
B 3 0 to 999.999 (mm)
C 4 0 to 99.9999 (mm)
D 5 0 to 9.99999 (mm)
The setting ranges indicated in this manual use the input setting unit "B".
4.2.1 PROCESS PARAMERTER
[PROCESS PARAMETER] PARAM 1.1/8
# - <WRK COUNT> # - <AUTO CORNER OVR.> # - <FIXED C.>
8001 WRK COUNT M 0 8007 OVERRIDE 0 8012 G73 n 0.000
8002 WRK COUNT 0 8008 MAX ANGLE 0 8013 G83 n 0.000
8003 WRK LIMIT 0 8009 DSC.ZONE 0.000 8014 CDZ-VALE 0
8015 CDZ-ANGLE 0
8016 G71 MINIMUM 0.000
# - <AUTO TLM> # - <T-TIP OFFSET> 8017 DELTA-D 0.000
8004 SPEED 0 8010 ABS.MAX. 0.000 8018 G84/G74n 0.000
8005 ZONE r 0.000 8011 INC.MAX. 0.000
8006 ZONE d 0.000
# ( )DATA ( )
WORK
PROCESS I/O PAR SETUP MENU
<WRK COUNT> (No. of workpieces machined)
# Item Contents Setup range (unit)
8001
WRK COUNT M
Set the M code that counts the No. of workpiece
repeated machining.
The No. will not be counted when set to 0.
0 to 99
8002
WRK COUNT
The current machining No. is displayed. Set the
initial value.
0 to 999999
8003
WRK LIMIT
Set the maximum No. of workpieces machined.
A signal is output to PLC when the No. of machining
times is counted to this limit.
0 to 999999
<AUTO TLM> (Automatic tool length measurement)
# Item Contents Setup range (unit)
8004
SPEED
Set the feedrate during automatic tool length
measurement.
1 to 60000 (mm/min)
8005
ZONE r
Set the distance between the measurement position
and deceleration start point.
0 to 99999.999 (mm)
8006
ZONE d
Set the tolerable zone of the measurement position.
If the sensor signal turns ON in front of d before the
measurement position‚ or if the signal does not turn
ON after d is passed‚ an alarm will occur.
0 to 99999.999 (mm)
