2. Monitor
2.2 COORDINATE
I-34
(c)
(d)
The buffer correction mode ends, and the corrected
data is written into to program.
If a program error has occurred, the error display
disappears.
(e)
The program execution resumes from the currently
stopped position.
(Example) An example of creating and executing the following program is given below.
If a program error (P62) occurs in the N125 block, the cause of the error is removed by
correcting the buffer.
N121 G28 X0 Y0;
N122 T1212;
N123 S1230 M3;
N124 G00 X68. Y201.;
N125 G01 X80. Y195.;
N126 Y150.;
N127 G02 X100. Y185. R20.;
N128 G01 X110.;
N129 G01 X120.;
N130 G01 X130.;
(a)
Start automatic operation.
1) A program error (P62) will occur
after N124 is executed.
N124 G00 X68. Y201.;
N125 G01 X80. Y195.;
N126 Y150.;
N127 G02 X100. Y185. R20.;
N128 G01 X110.;
N129 G01 X120.;
P62 F-CMD. NOTHING
Correct the program with the
same method as editing a
normal
p
ro
g
ram.
Press the
INPUT
key.
Confirm that the corrected
data is correct, and then
restart.
