2. Monitor
2.5 Resuming the Program
I-65
b) Type B
The main program to be restarted is searched for.
Press the
INPUT
key.
M: MODE <0> MEMORY <1> TAPE
T: TYPE <0> UNMODLE <1> TYPE 1 <2> TYPE 2
<3>T-TYP
O ( ) N ( 0) - ( 0) P ( 3) T(2) M(0)
M: MODE <0> MEMORY <1> TAPE
T: TYPE <0> UNMODLE <1> TYPE 1 <2> TYPE 2
<3>T-TYP RESEARCH EXECUTION
O ( ) N ( 0) - ( 0) P ( ) T(2) M(0)
[PROGRAM RESTART] MONITOR 5 .1/ 2
O 2000 N 0 - 0
<SUB> O 3000 N 0 - 0
[RESTART- (G54)] [RESTART-R]
X -80.000 X -80.000
Y -40.000 Y -40.000
Z 0.000 Z 0.000
C 0.000 C 0.000
O3000;
N1 G42 G01 X-10. Y-10. D05 F100;
M: MODE <0> MEMORY <1> TAPE
T: TYPE <0> UNMODLE <1> TYPE 1 <2> TYPE 2
<3>T-TYP RESEARCH COMPLETE
O ( ) N ( ) - ( ) P ( ) T( ) M( )
The "RESEARCH EXECUTION"
message appears during the search
and upon its completion the
"RESEARCH COMPLETE" message
is displayed.
A
ssign the block at which machining
is to restart and proceed with the
type 2 search.
O ( ) N ( 0 ) - ( 0 )
P ( 3 ) T ( 2 ) M ( 0 )
