Appendix 7.
Operation Messages on Setting and Display Unit
IV-29
Error No. Error message Details
E62 I/O PARAM ERR
∆
• The “EIA code” data set for I/O parameter is of an unusable code.
• The unusable codes are those used as the EIA standard codes
and the even hole codes.
E64 PROGRAM No.
ERR
∆
• The same No. as the program No. designated for program copy
was found in the memory.
• During tape input‚ the first character of the machining program
block is the program No. address “O” or “L”.
E65 PROG. No. DUPLl
∆
• During tape input‚ the same No. as the specified program was
found in the memory.
E66 NO PROG.
NUMBER
∆
• During tape input‚ the program No. was not found on the paper
tape‚ and a program No. was not designated on the screen’s data
setting area. Set the program No.‚ and input again.
E69 PROG. CHECK
MODE
×
• Search (operation search) was attempted during program check
(continuous or step).
• Retry search after the program check is completed‚ or after
resetting the program search
E70 TOOL No. DUPLl
∆
• A tool No. already registered was newly registered on the tool life
management screen.
E71 TOOL ENTRY
OVER
×
• Registration of data exceeding the max. No. of registerable tools
was attempted on the tool life management screen.
• When inputting the tool offset data onto tape‚ a compensation
number exceeding the specifications range was specified‚ and
that block could not be input. If the INPUT key is pressed again in
the input screen’ the input will continue from the next block.
E73 CAN’T
CALCULATE
×
• The coordinate value of the hole center cannot be obtained.
• Reset the measurement point, which must not applied to the
following conditions.
The measurement A point is the same as the Y coordinate of
the C point.
The measurement B is the same as the Y coordinate of the C
point.
The slope of the line through A and C point is the same as the
slope of the line through B and C point.
E74 MENU
IMPOSSIBLE
×
• Press the operation menu “= Input” or “+ input” during the tool
measurement.
• Press the operation menu “= Input” or “+ input” during the manual
value command mode.
• Press the screen selection menu on which “↓” is displayed during
the tool measurement.
• Press the screen selection menu on which “↓” is displayed during
the manual value command mode.
