2. Monitor
2.5 Resuming the Program
I-62
b) Type B
Press the
INPUT
key.
M: MODE <0> MEMORY <1> TAPE
T: TYPE <0> UNMODLE <1> TYPE 1 <2> TYPE 2
<3>T-TYP
O ( ) N ( 6) - ( 0) P ( 1) T(1) M(0)
M: MODE <0> MEMORY <1> TAPE
T: TYPE <0> UNMODLE <1> TYPE 1 <2> TYPE 2
<3>T-TYP RESEARCH EXECUTION
O ( ) N ( 6) - ( 0) P ( 1) T(1) M(0)
[PROGRAM RESTART] MONITOR 5 .1/ 2
O 1000 N 5- 0
<SUB> O N -
[RESTART- (G54)] [RESTART-R]
X -130.000 X -150.000
Y -10.000 Y -150.000
Z 0.000 Z 0.000
C 0.000 C 0.000
N6 Y-70.;
N7 X-20.;
M: MODE <0> MEMORY <1> TAPE
T: TYPE <0> UNMODLE <1> TYPE 1 <2> TYPE 2
<3>T-TYP RESEARCH COMPLETE
O ( ) N ( ) - ( ) P ( ) T( ) M( )
The "RESEARCH EXECUTION"
message appears during the search
and upon its completion the
"RESEARCH COMPLETE" message
is displayed.
A
ssign the block at which machining
is to restart and proceed with the
type 1 search.
(Example)
To restart from the
01000 N6 block
O ( ) N ( 6 ) - ( 0)
P ( 1 ) T ( 1 ) M ( 0 )
