2.8 LOCAL VARIABLE
I-75
Display item Explanation
<INVALID>
FEED-HOLD
OVERRIDE
EXACT
SNGL-BLOCK
MST-FIN
This indicates the modal state of the operation control status by the
#3003, #3004 command.
FEED-HOLD : Is displayed when command is programmed with
#3004 bit 0 set to 1, indicating that feed hold is
invalid.
OVERRIDE : Is displayed when command is programmed with
#3004 bit 1 set to 1, indicating that cutting
override is invalid.
EXACT : Is displayed when command is programmed with
#3004 bit 2 set to 1, indicating that the G09 (block
deceleration check) command is invalid.
SNGL-BLOCK: Is displayed when command is programmed with
#3003 bit 0 set to 1, indicating that block stop is
invalid.
MST-FIN : Is displayed when command is programmed with
#3003 bit 1 set to 1, indicating the state of
proceeding to the next block without waiting for
the M, S, T command completion signal.
2.8.1 Local Variable Data Display
(1) When local variable #1~#33 command exists in user macro or argument specification is made in user
macro subprogram call, if the block is executed, the execution result is displayed.
DISP LV. (1)
ACT. LV. (0)
A 1 0.0000
B 2 0.0000
C 3 0.0000
I 4
DISP LV. (1)
ACT. LV. (1)
A 1 1.0000
B 2 2.0000
C 3 3.0000
I 4
(Example)
When the following machining
program is executed and user
macro subprogram is called, data
as shown in the right is displayed on
the page of local variable display
level (1):
G65 P1 A1. B2. C3. ;
