2.8 LOCAL VARIABLE
I-76
(2) The relationship between the user macro subprogram call execution and display levels is as shown
below:
Display level (0)
1 0.1000
2 0.2000
3 0.3000
16
#1=0.1 #2=0.2
#3=0.3
G65 P1A1. B2.
C3. ;
M02;
G65P 10A10. B20.
C30;
M99;
M99;
G65 P1000A1000.
B2000 ;
M99;
G65 P100A100.
B200. ;
M99;
Display of
level 0
Display of
level 1
Display of
level 2
Display of
level 3
Display of
level 4
Display level (0)
17
33
Display level (1)
17
33
Display level (2)
17
33
Display level (3)
17
33
Display level (4)
17
33
Display level (2)
1 10.0000
2 20.0000
3 30.0000
16
Display level (3)
1 100.0000
2 200.0000
3
16
Display level (4)
1 1000.0000
2 2000.0000
3
16
Main (Level 0)
01 (Macro Level 1) 010 (Macro Level 2) 0100 (Macro Level 3) 01000 (Macro Level 4)
Display level (1)
1 1.0000
2 2.0000
3 3.0000
16
(3) A local variable display page is selected by using the page keys
PREVIOUS
PAGE
,
NEXT
PAGE
. Display can be
changed as desired independently of the executing level.
(Note) The local variables are not cleared even when power is turned OFF. They are cleared when a
macro is called.
