6. Data In/Out
6.2 DATA OUTPUT
I-243
(3) Data format
The data format is as follows:
Address Definition Details
N Parameter number The parameter # number is shown with the value following N.
A Axis number For axis data, the axis number is shown with the value following A.
The first axis will be AI.
T Axis system number For data per system, the system number is shown with the value
following T.
(1st system: T1, 2nd system: T2, PLC axis: T3)
P Parameter data The parameter data is shown with the value following P.
The following types of data format are used according to parameter type and display method.
(The address order in one block must use the following format.)
1) Common parameter (one data item per one # number)
N1084P0.001;
Parameter setting value
Parameter # number
(1) The output parameter setting value is the same format as the screen display.
2) Axis parameter
N2001A1P10000;
Parameter setting value
Axis number 1 to 4
# number on screen
(1) When multiple axes are displayed on one screen
The parameter data for when the parameters for multiple axes are displayed on one screen are
output per axis.
[Output example]
:
N2001A1P120000 ;
N2002A1P4000 ;
N2003A1P21 ;
:
N2001A2P12000 ;
N2002A2P4000 ;
N2003A2P21 ;
:
A
xis 2 data
A
xis 1 data
