6. Data In/Out
6.2 DATA OUTPUT
I-240
(4) For 2-part system
When using the 2-part system, the machining program output operation can be switched with the
parameters.
#1050
MemPrg
#1286
ext22/bit0
Details
0, 2, 4, 6 The machining program registered in the memory common for the systems
is output.
1, 3, 5, 7 OFF The machining program registered in the memory for the selected system
is output.
ON The machining program registered in the memory for each system is output
as one file (tape) delimited with the $ mark.
(Example) When parameter "#1050 MemPrg" is set to 1, 3, 5 or 7, and "#1286 ext22 bit0" is set to 1,
the machining programs registered in each system memory are output as one file (tape)
delimited with the $ mark.
E E E E E E E E E E
O O O1234 O $1 O N1 G28 X0 Y0 Z0 O N2 G00 X100. O N2 $2 O G28 X0 O O O
R B B B B B B B B R
Program body for System 1 Program body for System 2
