4. Parameters (User)
4.2 Machining Parameters
I-147
<AUTO CORNER OVR> (Automatic corner override)
# Item Contents Setup range (unit)
8007
OVERRIDE Set the override value for automatic corner override. 0 to 100 (%)
8008
MAX ANGLE Set the max. corner opening angle where
deceleration should start automatically.
If the angle is larger than this value‚ deceleration will
not start.
0 to 180 (°)
8009
DSC. ZONE Set the position where deceleration starts at the
corner.
Designate at which length point before the corner
deceleration should start.
0 to 99999.999 (mm)
<T-TIP OFFSET> (Wear data input)
# Item Contents Setup range (unit)
8010
ABS. MAX.
(For L system only)
Set the max. value when inputting the tool wear
compensation amount.
A value exceeding this setting value cannot be set.
0 to 999.999 (mm)
8011
INC. MAX.
(For L system only)
Set the max. value for when inputting the tool wear
compensation amount in the addition mode.
0 to 999.999 (mm)
<FIXED C.> (Fixed cycle)
# Item Contents Setup range (unit)
8012 G73 n
(For M system only)
Set the return amount for G73 (step cycle).
0 to 99999.999 (mm)
8013
G83 n
Set the return amount for G83 (deep hole drilling
cycle).
0 to 99999.999 (mm)
8014
CDZ-VALE
(For L system only)
Set the screw cut up amount for G76‚ G78 (thread
cutting cycle).
0 to 127 (0.1 lead)
8015
CDZ-ANGLE
(For L system only)
Set the screw cut up angle for G76‚ G78 (thread
cutting cycle).
0 to 89 (°)
8016
G71 MINIMUM
(For L system only)
Set the minimum cut amount for the final cutting in
G71‚ G72 (rough cutting cycle).
If the final cutting amount is smaller than this value‚
the final cut will not be performed.
0 to 999.999 (mm)
8017
DELTA-D
(For L system only)
Set the change amount to the command cut amount
D for G71‚ G72 (rough cutting cycle).
Each cut amount will be the value obtained by
adding or subtracting this value from command D‚
and thus‚ the amount can be changed each cut.
0 to 999.999 (mm)
8018
G84/G74 return
(For M system only)
Set up return length m at a G84/G74 pecking tap
cycle.
Note: Set “0” to specify a usual tap cycle.
0 to 999.999 (mm)
