4. Parameters (User)
4.2 Machining Parameters
I-159
4.2.5 Tool Measurement Parameter
[TLM PARAMETER] PARAM 1.8/8
#
8701 Tool Length
8702 Tool Dia
8703 OFFSET X
8704 Y
8705 RETURN
8706 FEED
# ( ) X( ) Z( )
WORK
PROCESS I/O PAR SETUP MENU
# Item Contents Setup range (unit)
8701 Tool length Set the length to the end of the touch tool. ±99999.999 (mm)
8702 Tool Dia Set the spherical diameter of the touch tool end. ±99999.999 (mm)
8703 OFFSET X Set the spindle center deviation amount from the
touch tool center in the X axis direction.
±99999.999 (mm)
8704 Y Set the spindle center deviation amount from the
touch tool center in the Y axis direction.
±99999.999 (mm)
8705 RETURN Set the return distance to contact the touch tool
against the workpiece again.
±99999.999 (mm)
8706 FEED Set the ederate when contacting the touch tool
against the workpiece again.
1 to 60000 (mm/min)
