3. Tool Offset (M system)
3.3 Tool Life
I
-125
Refer to "3 (I). Tool Offset (L system)" for L system.
3.3.2 TOOL LIFE Screen Data Display
(1) HEAD, NEXT, GROUP LIST screen
(Display only. No data can be set).
OFFSET REGIST LIFE MENU
[TOOL LIFE] TOOL 4.1/2
GROUP TOOL NO. ST FORM L-CMP R-CMP AUX LIFE USED
HEAD: 10000000 12345678 1 000 -345.678 100.000 12345 234 34(min)
NEXT: 80000000 87654321 0 000 45.678 30.000 12345 234 4(min)
<GROUP LIST>
10 20 30 40 50 60 70 80 90
100 200 300 400 500 600 700 800 900
1000 2000 3000 4000 5000 6000 7000 8000 9000
10000 20000 30000 40000 50000 60000 70000 80000 90000
100000 200000 300000 400000 500000 600000 700000 800000 900000
1000000 2000000 3000000 4000000 5000000 6000000 7000000 8000000 9000000
100000002000000030000000 40000000 50000000 60000000 70000000 80000000 90000000
Display item
Explanation
HEAD
NEXT
The tool numbers and TOOL LIFE data of the tools in HEAD and NEXT are
displayed.
When TOOL LIFE is ineffective, only the tool numbers are displayed.
GROUP LIST The group numbers registered as TOOL LIFE data are displayed.
A maximum of 90 group numbers are displayed on one screen. If the number of the group
numbers
exceeds 90, the screen is scrolled every line by using the
or
key.
10 20 30 40 50 60 70 80 90
100 200 300 400 500 600 700 800 900
1000 2000 3000 4000 5000 6000 7000 8000 9000
10000 20000 30000 40000 50000 60000 70000 80000 90000
10 20 30 40 50 60 70 80 90
100 200 300 400 500 600 700 800 900
1000 2000 3000 4000 5000 6000 7000 8000 9000
10000 20000 30000 40000 50000 60000 70000 80000 90000
One-line scroll by pressing
key.
OFFSET REGIST LIFE MENU
OFFSET REGIST LIFE MENU
