4. Parameters (User)
4.2 Machining Parameters
I-158
# Item Contents Setup range (unit)
8316 BARRIER TYPE I
(For L system only)
Set the shape of the right chuck and tailstock
barrier.
0: No area
1: Chuck
2: Tailstock
0/1/2
8317 DELIV. AX. NAME
(For L system only)
When the right chuck and tailstock barrier is
movable, set the name of the delivery axis.
When using the 2-system method and the delivery
axis is an axis in the other system, designate the
system as 1A, 1B or 2A, 2B. If the system is not
designated as A and B, the set system will be used.
A/B/..
(axis address)
1A/1B/..
2A/2B/..
(system designation)
0 (cancel)
8318 STOCK ANGLE (L)
(For L system only)
Set the angle for the left tailstock end section.
The angle will be interpreted as 90° if there is no
setting (0).
0 to 180 (°)
0: 90° default
8319 STOCK ANGLE I
(For L system only)
Set the angle for the right tailstock end section.
The angle will be interpreted as 90° if there is no
setting (0).
0 to 180 (°)
